Screencast Video: Webel SysMLv2 Ports analog audio mixer case study: Simulation of one channel with a mic and a 1/4" jack line level input (7 minute quick tour)

Icon class

icon_class

fas fa-film

icon_class_computed

fas fa-film

Tags and keywords

Keywords

Video style

Be sure to use full screen mode and set the video player quality to 4K (2160p)

Accompanies this Online course module:

Course module: The Webel SysMLv2 Ports audio mixer case study with detailed worked slides and Cameo (CATIA Magic) simulation screencast videos

The Webel SysMLv2 Ports analog audio mixer case study has three increasingly ambitious stages: STAGE #1 is the basics of modelling audio signals with ports and models and simulations of all the components of a mixer channel strip; STAGE #2 is a whole mixer channel (including variations on kinds of channels); STAGE #3 is the entire mixer. This video shows the main aim for STAGE #2.

The accompanying slide set starts with very simple examples for STAGE #1 as shown in this video:

Screencast Video: Webel SysMLv2 Ports analog audio mixer case study: Simulation of a simple demo mono audio signal i/o processing node (3 mins)

Then, after combining the components into various channel kinds for STAGE #2 we simulate an entire analog audio mixer in STAGE #3!

You can purchase standalone access to the SysMLv2 Mixer Ports course module or save with the Webel SysMLv2 Combined online courses bundle, which includes the MASSIVE Webel SysMLv2 Language course, the Webel Balls & Boxes worked sample problem and exercises slide set, the Webel Mixer Ports audio mixer case study with slides and videos, and the Webel Cameo SysMLv2 Simulation video series.

All course purchases are one-off and grant you ongoing access to all per-course resource additions and updates. Payments are processed securely by Stripe. Accepts most credit cards, Apple Pay, Google Pay, AfterPay and more.
