Screencast: Cameo Simulation Toolkit: v19SP3: Analysis: When a Property is typed by an abstract Block an instance of a concrete specialising Block will automatically be created and assigned even when the lower multiplicity is 0
Video style
This screencast video is an analysis of this suspected issue:
It also includes a nice demo of using an Activity and Actions to simulate instance creation and assignment in Magic Model Analyst® (Cameo Simul
Cameo Simulation Toolkit: v19SP3: GOTCHA/BUG: When a Property is typed by an abstract Block an instance of a concrete specialising Block (where available) will automatically be created and assigned even when the lower multiplicity is 0
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
MagicDraw/Cameo 19SP3: Activity Diagrams: Pin display mode 'Position of Labels' does not work correctly for 'Name And Type Labels Inside', only shows the Name inside (not the Label)
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
UML/SysML: MagicDraw/Cameo: 19SP3: Instance Table Diagram sometimes does not display the values for nested value properties
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
MagicDraw/Cameo: 19SP3: Although a 0..* or 1..* Property can carry more than one value, the interface only permits assignment of a single Property::defaultValue through the specification dialog
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
UML: Cameo Simulation Toolkit 19SP3: GOTCHA: CreateObjectAction ignores an Artifact as 'classifier' even though Artifact is a Classifier
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
UML/SysML: Cameo Simulation Toolkit 19SP3: A parent Activity with a DecisionNode that uses a Activity as a decisionInput Behavior terminates immediately after the decisionInput terminates (but OpaqueBehavior works)
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
UML/SysML: Cameo Simulation Toolkit 19SP3: GOTCHA: Will not evaluate a guard using a token from a decisionInputFlow UNLESS a decisionInput Behaviour is explicitly defined (but Alf does)
This page identifies a possible issue, inconsistency, concern, error, or bug!
One of the ways Webel IT Australia helps promote tools, technologies, and languages is by donating a lot of time identifying, tracking, and reporting potential issues, in order to help vendors and developers improve the tools and technologies. In some cases, we also offer workarounds and advice for users. All issues tracked on our public site are offered most constructively and with sincerest gratitude to the tool vendors and technology developers.
DISCLAIMER: Vendors do not officially endorse issue analysis by Webel IT Australia.
