SysMLv1: Cameo Simulation Toolkit: Cases for Transitions triggered by Signals sent direct to a remote target vs via Ports [with mini video]
This content has been marked as discussing an ADVANCED topic!
© Copyright 2020 Darren R C Kelly (Webel IT Australia). All rights reserved.
This full length tutorial is a case study of the telephone dialer StateMachine shown in 'Figure 14.7 Composite State with two States' of the UML-2.5.1 specification.
A very simple demonstration of sending a Signal using a SendSignalAction and receiving it with an AcceptEventAction within Activities. Uses SysML but the same applies to UML.
Uses Cameo Simulation Toolkit for MagicDraw SysML and Cameo System Modeler.
